NMT-SDL-512 Capacitor tunnel drying furnace

Specifications:

NMT-SDL-512
1. Inner Chamber Dimensions: Width 1000mm * Height 650mm * Depth 1640mm;
2. External Dimensions (approximately): Width 1420mm * Height 1760mm (excluding motor height) * Depth 1880mm;
3. Temperature Range: Adjustable from room temperature +20°C to +200°C, operating temperature 150°C;
4. Instrument Temperature Fluctuation: ≤±1°C;
5. Temperature Uniformity: ≤±2°C (no-load), ≤±4°C (loaded), measured 10 minutes after feeding;
6. Heating Rate: ≤8°C/min;
7. Casing Temperature: Equipment temperature within 150°C, casing temperature not exceeding room temperature +15°C, excluding the furnace mouth and joints;
8. Air Circulation: Up-and-down circulation;
9. Power Supply: Three-phase five-wire, 380V, 50Hz;
10. Total Power: Approximately 28kW
