NMT-SDL-688 Automobile interior tunnel furnace

Specifications:

NMT-SDL-688

1. Inner Tank Dimensions: Drying Zone: Length 10,000mm * Net Height 300mm * Inner Width 1100mm;
2. External Dimensions (approximate): Total Length 14,200mm * Total Height 1400mm (excluding motor height) * Total Width 1600mm, Floor-to-Belt Height 850mm, Inner Width 1100mm, Infeed Height 300mm; Drying Section Total Length 10,000mm, Divided into 10 sections, each 1000mm long, with adjustable baffles at the front and rear of the drying section; Infeed Section 1000mm long, Cooling Section 2000mm long, Discharge Section 1000mm long;
3. Temperature Range: Adjustable from room temperature to +250°C, with 10-stage temperature control in the heating section;
4. Temperature Uniformity: ≤±3°C (no load);
5. Air Circulation: Forced air with up-and-down circulation;
6. Total Power: Approximately 110kW
