NMT-SDL-687 Automobile interior tunnel furnace

Specifications:

NMT-SDL-687

1. Inner Tank Dimensions: Heating Zone Length 5.0m (Three-stage Temperature Control) * Net Height 0.1m * Inner Width 2.0m;
2. External Dimensions (Approximate): Total Length 7.6m * Height 1.5m * Width 2.3m; Conveyor Surface Height 0.84m ±0.025m Adjustable from Ground Level; Feed Zone 2m, Heating Zone 5m (Three-stage Control), Discharge Zone 0.6m;
3. Temperature Range: Room Temperature to +300°C;
4. Casing Temperature: Not to exceed ambient temperature +10°C.
5. Air Circulation: Hot air circulates from front to center;
6. Power Supply: Three-phase, five-wire, 380V, 50Hz;
7. Power: Total Power 110kW
