NMT-SDL-508 Battery capacitor tunnel furnace

Specifications:

NMT-SDL-508

1. Material Dimensions and Weight: Length 932mm (conveyor line width), Width 222mm (conveyor line conveying direction), Height 163mm (opening height); Unit Weight 120kg;
6-piece batches, intermittent stepping conveying (manually controlled); Material Material: Carbon Steel;
2. Temperature Zone Separation: The constant temperature heating section inlet has an automatic lift insulated door; the constant temperature heating section and cooling section inlet have an automatic lift insulated door, sharing a single automatic lift insulated door; the cooling section outlet has an automatic lift insulated door;
3. Heating Temperature Range: Adjustable from room temperature to 100°C, with two constant temperature heating zones (with temperature detection and display, unified settings, independent temperature control, and separate display);
4. Cooling Temperature Range: Room temperature to 35°C, with one cooling zone (with temperature detection and display);
5. Temperature Recording: The constant temperature heating section has six temperature detection points (front, center, rear, and sides), which record temperature data with an adjustable detection frequency (0-60 minutes);
6. Machine Orientation: Facing the operating surface, right-hand inlet and left-hand outlet. 7. Continuous working time: Continuous working time is greater than or equal to 120 hours;
