NMT-ZN-620 Capacitor lithium battery automatic drying tunnel furnace

Specifications:

NMT-ZN-620
1. Inner Chamber Dimensions: Width 900mm * Height 400mm * Depth 2590mm;
2. External Dimensions (approximately): Width 1260mm * Height 1760mm (excluding motor height) * Depth 2830mm;
3. Temperature Range: Adjustable from room temperature +20°C to +200°C, operating temperature 150°C;
4. Instrument Temperature Fluctuation: ≤±1°C;
5. Temperature Uniformity: ≤±3°C (no-load);
6. Heating Rate: ≤8°C/min;
7. Casing Temperature: Equipment temperature within 150°C, casing temperature not exceeding room temperature +15°C, excluding the furnace mouth and joints;
8. Air Circulation: Up and down circulation;
9. Power Supply: Three-phase five-wire, 380V, 50Hz;
10. Total Power: Approximately 30kW
