NMT-QC-9612
1. Single liner dimensions: W2600*D1400*H300 (mm), four independent liner layers;
2. External dimensions: W3000*D2120*H1970 (mm);
3. Temperature range: Room temperature to 250°C (normal use);
4. Heating time: 250°C ≈20 minutes
5. Temperature Uniformity: ±1.5% (no-load test)
6. Protection Devices: PID auto-tuning, automatic constant temperature, automatic timing, timed alarm and power-off upon reaching a certain temperature, over-temperature power-off, leakage protection, motor overload protection, and other control circuit fuses, blanking switches, and other electrical accessories.
7. Intelligent temperature controller with automatic PID calculation, LED display, and SSR solid-state relay output for precise temperature control.
8. Inner chamber made of mirror-finished 304# stainless steel, fully welded with argon arc welding to prevent dust from forming. Outer casing made of 2.0mm cold-rolled steel with high-temperature powder coating.
9. Double over-temperature protection for greater safety and reliability.
10. Fast heating time and stable and accurate temperature.
11. First-class domestic thermal insulation and heat isolation technology for excellent sealing.
12. Low outer casing temperature, minimal impact on indoor ambient temperature.
13. Energy-saving and high safety performance.
14. Total power: 52kW (380V 50Hz).
If you have special needs or customization, please contact us.
We can design custom industrial ovens and furnaces to your specifications.
